Holmes Daniamant L170 FACE KIT with a side view of LED light and separate mounting support on white background.

Holmes Daniamant L170 FACE KIT WITH SUPPORT – LED, SOLAS/USCG, 5 years without maintenance

Share this product

The Daniamant L170 kit consists of 1 Holmes L170 beam (PN 61-001A) and 1 assembly support (PN 61070A), providing a complete and ready solution for life buoy installation as required by solas, med and USCG. The L170 light uses low -consumption LED technology, with a minimum intensity of 2 chandellas and duration of more than 2 hours, according to the international requirement. It is automatically activated by contact with water and designed to function for up to 5 years without maintenance, simplifying inspections and reducing operating costs. PN 61070A support guarantees secure installation on commercial vessels, platforms and offshore vessels.

include in quote

EUROSUL Code:

092655

Part Number:

L170 - 61-001A

Product Description Documentation

Features:
Material: High resistance polymer (body of light and support)
Fixers: robust support PN 61070A included in the kit
Design: compact, lightweight, impact resistant and sealed
Color: Black body with white lens and black support

Applications:
Solas certified ships
Offshore platforms and commercial vessels
Installation in Lung Books

Benefits:
Readiness: 5 years of validity without the need for battery exchange
Durability: Sealed Body, IP68, resistant to the fall of up to 76 meters
Safety: full compliance with solas, med, USCG

Technical Specifications:
Light Source: White Led Figant
Light intensity: ≥ 2 candelas
Autonomy: ≥ 2 hours
Energy Source: Integrated Lithium Battery
Activation: Automatic by contact with water
Validity: 5 years without maintenance
Water resistance: IP68 – submersible up to 50 m
Maximum installation height: 76 m
Weight (Full Kit): Approx. 420 g

Certifications:
Solas
Medi
USCG
Transport: Un3091 – Class 9 (Integrated Lithium Battery)
