VHF Antenna 117-137MHz JOTRON
JOTRON CXL3-1LW VHF antenna for the 117 to 137 MHz band, designed for fixed aeronautical communication stations. It offers reliable performance, compatibility with TR810 and TR910 radios, and practical installation for professional use.
Contact a specialist.
Specifications
Overview
VHF antenna for fixed station use, designed for operation in the 117 to 137 MHz band. The JOTRON CXL3-1LW is suited to aeronautical communication systems that require stable coverage and integration with TR810 and TR910 radios.
Application and use
Used in fixed VHF communication installations, especially at bases and aeronautical operating points. It is a suitable choice for external mast-mounted applications where consistent professional performance is required.
Construction characteristics
| Model | CXL3-1LW |
| Antenna type | VHF |
| Frequency range | 117-137 MHz |
| Impedance | 50 ohms |
| Gain | 0 dBd |
Technical specifications
| Part number | 91794 |
| Compatibility | TR810, TR910 |
| Polarization | Vertical |
| Bandwidth | 18 MHz |
| SWR | < 1.6 |
Performance
| Maximum power | 150 W |
| Approx. length | 1.51 m |
| Approx. weight | 0.80 kg |
| Connector | Type N female |
| Mounting | 16 to 54 mm mast tube |
Marking and traceability
| SKU | 003073 |
| Part number | 91794 |
| IMPA | 232076 |
Handling, service life and disposal
Store and install the antenna in a dry location, with proper fastening and periodic inspection of the mounting points and connector. When replacing the unit, dispose of components according to applicable environmental practices and local rules for electronic materials.
Frequently Asked Questions (FAQ)
It is intended for fixed VHF communication stations in the 117 to 137 MHz band. It is used in aeronautical applications that require stable coverage and compatibility with matching radios.
The model is compatible with TR810 and TR910 radios. This makes integration easier in existing systems.
The antenna has 50 ohms impedance, 0 dBd gain, and 18 MHz bandwidth. It also offers SWR below 1.6 and maximum power of 150 W.
It is mounted on a 16 to 54 mm mast tube. The connector is a type N female, which helps with connection to suitable infrastructure.
The main identification data are SKU 003073, part number 91794, and IMPA 232076. These codes help with lookup, replacement, and stock control.
