Cargo Net 3TO Chutuo
The 3x3m multifilament polypropylene cargo net is a practical solution for handling and lifting loads on board. Lightweight, durable and easy to use, it helps keep operations safer and more efficient.
Contact a specialist.
Specifications
Overview
Multifilament polypropylene cargo net with 3-strand construction and 3.0 x 3.0 m dimensions. It is designed to support onboard load handling and lifting, with a focus on practicality and operational organization.
Application and use
Used in onboard operations to secure, move and lift loads with a crane or compatible lifting equipment. The 3-strand configuration helps distribute the load in routine applications.
Construction characteristics
| Material | Multifilament polypropylene |
| Rope construction | 3-strand |
| Border rope | 16 mm |
| Mesh rope | 20 mm |
Technical specifications
| Type | Cargo net |
| Length | 3 m |
| Width | 3 m |
| Breaking load | 3TO |
| Part number | 20203-1221 |
| IMPA | 232152 |
Marking and traceability
| SKU | 001125 |
| Part number | 20203-1221 |
| IMPA | 232152 |
For best service life, keep the net clean, dry and stored away from excessive heat, oil and aggressive chemicals. Inspect for wear, cuts and deformation before each use; remove from service any item with visible damage or doubtful integrity.
| Código Eurosul | Dimensão | Carga Máxima | Material | Malha | Cabo (malha/borda) | IMPA |
|---|---|---|---|---|---|---|
| 001124 | 2,5 x 2,5 m | 4.500 kgf | PP multifilamento | 200 mm | 16 mm / 20 mm | 232151 |
| 001125 | 3,0 x 3,0 m | 4.500 kgf | PP multifilamento | 200 mm | 16 mm / 20 mm | 232152 |
Frequently Asked Questions (FAQ)
It is intended for handling, securing and lifting loads on board. The 3-strand construction helps distribute the load during operation.
The net measures 3.0 x 3.0 m. These dimensions suit routine onboard operations.
The product is made of multifilament polypropylene. This material is widely used in marine applications because it is lightweight and easy to handle.
Commercial identification includes SKU 001125, part number 20203-1221 and IMPA 232152. These details help with purchasing and catalog traceability.
