Navigation Luminaires CXH101P Series – For large vessels
Share this product
CXH101P series lamps are developed for navigation signaling on large vessels, offering maximum visibility, robustness and compliance with international standards. Compatible with 60W and 65W lamps, operate in 24V, 110V or 220V tensions with P28S type base. They have IP56 degree of protection and solas/med certifications, being ideal for continuous operation in demanding maritime environments. Available in stabs, fire, mast, stern and total light models, with visibility of up to 6 nautical miles and views of vision between 112.5 ° and 360 °.
EUROSUL Code:
091637
Approvals:
Technical Specifications:
Operating Voltage: 24V, 110V or 220V
Lamp power: 60W or 65W
Base: P28S
Degree of Protection: IP56
Certifications: Solas/Med
Material: Body in anti -corrosion material for maritime environment
Light Type: Continuous (Colreg)
Applications:
Cargo ships, tugboats and offshore vessels
Navigation lighting according to international standards
Maritime safety position signaling
Available Models – CXH101P Lamps:
| Code Eurosul | Name | Model | Visibility | Viewing Angle | Color | IMPA Code |
|---|---|---|---|---|---|---|
| 091637 | Starboard Light | CXH1-101P | 3N. miles | 112.5° | Green | 370422 |
| 091638 | Port Light | CXH2-101P | 3N. miles | 112.5° | Red | 370423 |
| 091639 | Masthead Light | CXH3-101P | 6N. miles | 225° | White | 370421 |
| 091640 | Stern Light | CXH4-101P | 3N. miles | 135° | White/Yellow | 370424 |
| 091644 | All-Round Light | CXH6-101P | 3N. miles | 360° | Red/Green/White | 370426-28 |
