Foldable Radar Reflector 470mm EMF
The TLF-470A foldable passive radar reflector is designed to improve vessel radar visibility, supporting safer navigation in low-visibility conditions. Compact, lightweight, and easy to stow, it is a practical solution for vessels and lifesaving equipment that need reliable onboard performance.
Contact a specialist.
Specifications
Overview
Foldable passive radar reflector for onboard use, designed to improve vessel radar detectability. The TLF-470A combines a compact format with a strong echo area, making it a practical choice for maritime safety applications.
Application and use
Suitable for vessels and lifesaving equipment that need reliable radar visibility in service. The recommended minimum mounting height is 2 m above the waterline to support effective performance underway.
Construction characteristics
| Type | Foldable passive radar reflector |
| Model | TLF-470A |
| Foldable | Yes |
| Color | Orange |
Technical specifications
| Radar echoing section | 40 m² |
| Edge length | 470 mm |
| Minimum mounting height | 2 m |
| Operating temperature | -30 °C to 65 °C |
| Total weight | Less than 2 kg |
Compliance and certification
| SOLAS | MSC.48(66) Ch. IV; MSC.164(78) |
| CCS | Certificate of Type Approval |
Marking and traceability
| SKU | 091096 |
Handling, service life and disposal
Keep the reflector clean, dry, and stored in its bag when not in use. Inspect the reflector segments and support system regularly before installation. At end of service life, dispose of it according to the vessel’s environmental procedures and applicable regulations.
Frequently Asked Questions (FAQ)
It improves vessel radar visibility, supporting safer navigation. It is suitable for onboard use and lifesaving equipment.
The model has a 40 m² radar echoing section, 470 mm edge length, and a minimum mounting height of 2 m. The stated operating range is -30 °C to 65 °C.
Yes. The foldable design makes onboard storage and handling easier, especially in limited spaces. It also comes with a storage bag and support mast segments.
The product is SOLAS certified and has CCS class approval. The SOLAS reference listed in the record is MSC.48(66) Ch. IV; MSC.164(78).
