Explosion-proof Horn Speaker DSP-15 EEXMN 8 Ohms

Eurosul Code: 005270

Part Number: 608001

Approvals:

The DSP-15 EEXMN Explosion-proof Horn Speaker is designed for industrial and maritime environments where safety is essential. Built with anti-static plastic, it offers durability and lightweight properties. With a nominal power of 25W and adjustable tappings, this horn speaker provides outstanding sound pressure levels, suitable for high-demand environments. Certified with ATEX and IECEx protection for hazardous zones, it comes equipped with two M20 cable entries for easy installation.

Industrial Quote Request

include in quote

Fast international shipping for marine fleet supplies.
Contact a specialist.

Specifications

Benefits
Explosion-proof: Suitable for harsh industrial environments
High acoustic performance: Sound pressure up to 118 dB
Antistatic material: Provides additional safety in hazardous areas
Easy installation: Includes mounting bracket and connectivity options

Applications
Oil and gas industries
Marine and offshore installations
Hazardous industrial environments

With its durability and certification for hazardous zones, the DSP-15 EEXMN horn is a reliable choice for safe communication systems in high-risk areas.

Technical Specifications
Material: Antistatic plastic, black color
Weight with transformer: 2.2 kg
IP rating: IP66/IP67
Maximum/minimum operating temperature: 60°C / -50°C
Rated/maximum power: 25W / 30W
SPL (sound pressure) 1W/1m: 106 dB
SPL rated power: 118 dB
Effective frequency range: 380 – 8000 Hz
Dispersion angle 1kHz / 4kHz: 120° / 37°
Certifications: ATEX, IECEx, Inmetro, EAC, UL/CSA, UKEX
