Marine Reflector E40
Share this product
The Naval E40 reflector is a robust equipment designed for maritime and industrial applications, offering intense lighting and high durability. Built on stainless steel, with tempered glass dome and anodized aluminum reflector, it ensures corrosion resistance and excellent IP67 seal. Its angle adjustment up to 90 ° up and 45 ° down provides flexibility in the direction of light.
EUROSUL Code:
092292
Approvals:
Benefits:
Durable Material: Stainless steel and tempered glass for greater resistance.
IP67 Protection: Sealing against dust and temporary submersion.
Lighting adjustment: Adjusting angle of 90 ° up and 45 ° down.
CCS Certification: Compliance with international security standards.
Applications:
Ships and vessels: lighting of coves and load areas.
Cais and Docks: Cargo and discharge areas in ports.
Tunnels and Squares: Lighting of large areas that require high performance.
The E40 naval reflector ensures visibility and safety, being ideal for demanding environments.
Technical Specifications:
| Model | Voltage | Power | Socket | Luminous Flux | Material | Protection Class | Adjustment Angle | Dimensions (mm) | Weight | Certification |
|---|---|---|---|---|---|---|---|---|---|---|
| TG67-C500 | 110V / 220V | 500W | E40 | 8,500 lm | Stainless steel, tempered glass, anodized aluminum | IP67 | 90° upward / 45° downward | L390 x W145 x H340 | 5.5 kg | CCS |
| TG67-C1000 | 110V / 220V | 1000W | R7S | 22,000 lm | Stainless steel, tempered glass, anodized aluminum | IP67 | 90° upward / 45° downward | L390 x W145 x H340 | 5.5 kg | CCS |
