BusSola B-81 Wm Ritchie

Share this product

Ritchie’s B-81 WM Nautical compass is designed for simple panel installation, being ideal for commercial and rescue vessels. It has a Combidamp 3 ″ (72 mm) dial, direct reading, Nitevu Green Integrated Night Lighting and internal compensators for accurate magnetic deviation. Its structure is developed in high temperature composed material to expand the operational range.

include in quote

EUROSUL Code:

090281

IMPA Code:

330211

Part Number:

B-81-WM

Approvals:

Product Description Documentation

Features
Display: CombiDamp 3″ (72 mm)
Night illumination: Integrated NiteVu (green)
Compensators: Internally adjustable
Sun shield: Movable
Mount: Adjustable and removable with screws
Dial movement: Hardened steel pivot with sapphire jewel
Repairability: 100% repairable
Certification: MED compliant with directive 2020/1170 and SOLAS (MED/4.23)

Applications
Ideal for use on rescue vessels
Lifeboats
Coastal navigation
Excellent performance in extreme conditions

Benefits
high navigation accuracy
heat and impact resistance
reliability in critical missions
meets the most demanding international standards

Technical Specifications
Model: B-81 WM
Dial diameter: 3″
Illumination: NiteVu (green, 12V)
Material: High thermal resistance composite
Certifications: SOLAS/MED (IMO Res. MSC.48(66), ISO 25862:2019)
